250 SC FACTORY
Data Sheet
Engine |
2 stroke |
Engine size |
249.70 cc |
Bore & Stroke |
72.80 x 60 mm |
Fuel system |
- |
Battery |
- |
Cylinder lubrication |
- |
Cylinder |
Nikasil coated cylinder |
Lubrication |
2% oil pre-mix |
Fuel |
Unleaded gasoline 98 Octane |
Carburetor |
Keihin Ø 28 mm |
Cooling |
Liquid system |
Start |
Geared system with folding lever |
Exhaust |
Steel header pipe with an integrated aluminum muffler |
Systeme Allumage |
- |
Transmission |
5 speed sequential gearbox with security selector system to prevent false shifts. Primary gear drive chain secondary drive |
Clutch |
Hydraulic, multidisc in oil bath |
Ignition |
Hidria digital |
Alternateur |
- |
Frame |
Tubular section frame Chrome-Molybdenum |
Fuel Tank |
Nylon 2.6 L capacity (... US gal) |
Brakes |
Hydraulically activated, floating 185 mm (7.28 in) front and 145 mm (5.71 in) rear |
Front suspension |
TECH ALUMINUM Ø 39 mm (1.5 in) fork, 165 mm (6.50 in) travel, with 2 settings |
Rear suspension |
Progressive link system with single adjustable shock absorber, 175 mm (6.89 in) travel Rear shok |
Rear shock absorber |
REIGER SHOCK ABSORBER WITH 2 SETTINGS |
Front wheel |
Morad 21” graphit anodized aluminum rim and aluminum hub, steel spokes with Michelin tube-type tire |
Rear wheel |
Morad 18” graphit anodized aluminum rim and aluminum hub, steel spokes with Michelin tubeless tire |
Weight |
68.5 kg |
Wheelbase |
1322 mm (52.05 in) |
Ground clearance |
310 mm (12.20 in) |
Seat height |
645 mm (25.39 in) |
